Standard punch systems

Share Ball bearing draw stud reduces operating force

• suitable for
• Mild steel (St37), plastic and aluminium up to 3.5 mm
• Operation
• Manual / hydraulic
• Predrilling
• Draw stud 9.5 mm dia., pilot drill 9.7 mm dia. 50360183 Draw stud 11.1 mm, pilot drill 12.7 mm 50344102Draw stud 19.0 mm dia., pilot drill 20.5 mm dia. 50344030
• Scope of delivery
• Complete system including punch, die and draw stud for manual operation
• Additional information
• 50042181 draw stud without ball-bearing
• 52085634 only for 22.5 mm / Pg16, 2.5mm steel plate and 2mm V2A

Ordering information

• Hole size – Max. material thickness mm
• True dimensions mm – Standard size Pg
• 15,2 – Pg 9
• 16,2 – -
• 18,6 – -
• 20,4 – Pg 13
• 22,5 – Pg 16
• 22,5 – Pg 16
• 25,4 – -
• 28,3 – Pg 21
• 28,3 – Pg 21
• 30,5 – -
• 32,5 – Pg 32
• 34,9 – -
• 37,0 – Pg 29
• 38,1 – -
• 40,5 – -
• 44,5 – -
• 47,0 – -
• 47,6 – -
• 49,6 – -
• 50,8 – -
• 54,0 – Pg 42
• 57,2 – -
• 60,0 – Pg 48
• 61,5 – -
• 63,5 – -
• 66,7 – -
• 69,9 – -
• 74,0 – -
